EZFace T8
Next Generation, Contactless, AI-based Temperature & Facial Recognition Time Attendance & Access Control terminal with accurate temperature sensor
Introduction
EZFace-T8 in Pakistan – the most powerful biometric + temperature sensor machine by Limton. Most advanced Face + Temperature Recognition Terminal; offering Long Range Face Recognition unmatched speed & measurement accuracy. It is an ergonomic machine with a highly stable & strong core design. Based on Linux operating system, the machine can enroll up to 24,000 users & also capable to work in a unique “stranger” mode. EZFace-T8 is most suitable for time attendance & access control in all organizations.
Features
Liveness Detection
Detect real-time liveness & ensure live user presence
Advanced Face Recognition Algorithm
Accurately recognize live faces in less than 0.5s
Stranger Mode
Restrict strangers’ movement based on temperature measurement
Temperature Measurement
Speedy & accurate temperature measurement with high temperature alarm
Built-in Light Sensor & LED fill light
Automatically adjusts opening & closing of the fill light
Accurately tracks human face under different lighting conditions
Stable Operating Systems
Using Linux operating system
Multiple Interfaces Support
Support TCP/IP, UDP, HTTP, DNS, DDNS, SMTP, others
I/O, WG26, WG34, RJ45, RS485 interfaces
Large HD Display
8-inch IPS full-view HD display, without streaking and delay
Large User Memory
Up to 24000 faces & 160,000 transactions capacity
Intelligent Camera Technology
2D & 3D noise reduction
Intelligent exposure & smart enhancement settings for the face
Specifications
| Hardware | |
| Processor | Dual-Core Processor+ 1G memory + 16G flash |
| Operating system | Linux |
| Viewing angle | Vertical viewing: 30°; Horizontal viewing: 30° |
| Measurement range | 16℃ – 40℃ (Indoor without wind) |
| Temperature measurement lens & sensor | European |
| Temperature Measurement accuracy | ±0.3℃ |
| Temperature resolution | 0.1℃ |
| Temperature measurement distance | ≤80cm |
| Measurement response time | 300ms |
| Performance | |
| Recognition height | 1.2 ~ 2.2 meters, angle adjustable |
| Recognition distance | 0.3 ~ 1.5 meters, depends on lens [for temperature monitoring 30 CM] |
| Recognition time | Less than 0.5 seconds |
| Storage capacity | 160,000 capture records |
| Face capacity | up to 24,000 |
| Interface | |
| Network interface | 1 RJ45 10M / 100M adaptive Ethernet port, Gigabit Ethernet port can be customized |
| Wiegand interface | 1ch Wiegand interface input/output |
| Communication interface | 1ch RS485 interface |
| USB interface | 1ch USB interface |
| Camera | |
| Camera | Dual cameras, visible and near-infrared, support live detection |
| Effective pixels | 2MP, 1920*1080 |
| Min Illumination | Color 0.01Lux @F1.2(ICR); B/W 0.001Lux @F1.2 (ICR) |
| Function | |
| LAN/ WAN support | Yes |
| Regular | |
| Working humidity | 0～90% relative humidity, no condensation |
| Power | DC12V/2A, 20W(MAX) |
| Equipment size | 252(L) * 136 (W) * 26 (T) mm |
| Screen size | 8 inches IPS HD screen |
| Weight | 1.7 kg |
SPECIAL CONSIDERATIONS:
- Temperature measurement accuracy standards
- Temperature should be maintained
- Machine installation in indoor premises.
- heating or cooling source should be avoided in machine surroundings
- For taking accurate temperature, acclimatize user in the room machine is installed, leave forehead unobstructed/uncovered, accurately put face & forehead in projection area on the machine display
- The forehead temperature will be lower than the actual temperature if there is oil/makeup/mask/wrinkles/cloth, etc. on the forehead
For further information about the products in this category & to discuss how Hand Geometry technology can assist your organizational requirements, please contact us sales@limton.com.pk
